Specifications
General Information
EP500Pro AC Rated Power:
3000W
3000W<load<3750W,2min
3750W<load<4500W,5s
4500W<load<6000W,500ms
(peak 6000W)
3000W<load<3750W,2min
3750W<load<4500W,5s
4500W<load<6000W,500ms
(peak 6000W)
EP500Pro Net Weight:
≈83kg (182lbs)
Dimensions:
500*300*760mm (22.8*11.8*29.9in)
Battery Capacity:
5100Wh
Battery Cell Type:
LiFePO4
Rated Life Cycle:
6000+
Charge Temperature:
0°C ~ 40°C (32°F ~104°F)
Storage Ambient Temperature:
0°C ~ 45°C (32°F ~113°F)
Working Environment humidity:
10-90%
Certification:
PSE, FCC, CE, UN38.3, msds, UL, SAA and ROHS
Warranty Perior:
5 Years
Input Specs
EP500Pro AC Input:
3000W Max
EP500Pro PV Input:
2400W Max,
35-150VDC, 12A*2,12V/24V,8.2A
35-150VDC, 12A*2,12V/24V,8.2A
Output Specs
EP500Pro USB-C:
2*100W
EP500Pro AC:
220-240VAC*3
USB-A:
2*Quick Charging, 36W Total, 2*5VDC, 3A Total
Cigarette Lighter:
1*12VDC, 10A
RV (Aviation Port):
1*12VDC, 30A
DC 5521:
2*12VDC
Wireless Charging Pad:
2*5/7.5/10/15W
